UHF 주파수 대역의 라벨태그는 자산관리, 의료, 제조, RTLS 등 긴 인식거리 (1 ~ 20미터)가 필요한 어플리케이션에 적합합니다.
CL7203S-6535
This is a most common and wide use RFID tag – paper label with adhesive.
Most in fixed asset management, warehousing management, inventory control, medicine tracking and so on.
Parameters
| Functional specifications | |
|---|---|
| Protocol | EPC Class1 Gen2; ISO18000-6C |
| Frequency | 902-928MHZ ; 866-868MHZ |
| IC type | Impinj monza R6-P |
| Memory | EPC 128(96) bits User memory 32(64)bit |
| Write cycles | 100,000 items |
| Size | 65*35MM, Thickness 1.25MM |
| Operation Temperature | -40℃ to 85℃ |
| Storage Temperature | -40℃ to 85℃ |
| Read range | 500CM-(902-928MHZ) (Fix reader) 4500CM-(865-868MHZ) (Fix reader) 250CM-(902-928MHZ) (Handheld reader) 220CM-(865-868MHZ) (Handheld reader, 2W EIRP) |
| Certifications | Reach Approved, RoHS Approved, CE Approved |
| Customization | Write EPC, Printing LOGO, Barcode |
CL7203E-3613
Features
| Functional specifications | |
|---|---|
| Protocol | EPC Class1 Gen2; ISO18000-6C |
| Frequency | 902-928MHZ ; 866-868MHZ |
| IC type | Alien higg4 |
| Memory | EPC 96bit User memory 512bit |
| Write cycles | 100,000 items |
| Size | 4215MM, Thickness 2MM, Hole 4MM2 |
| Operation Temperature | -20℃ to 180℃ |
| Storage Temperature | -40℃ to 280℃(280℃ for 50 minutes, 250℃ for 150 minutes) |
| Weight | 2.2g |
| Material | High temperature resistant material |
| IP rating | IP68 |
| RF Specification | |
|---|---|
| Read range | 650CM-(902-928MHZ) (Fix reader) 650CM-(865-868MHZ) (Fix reader) 350CM-(902-928MHZ) (Handheld reader) 350CM-(865-868MHZ) (Handheld reader) |
| Mounting | 3M back glue or Screw |
| Certifications | Reach Approved, RoHS Approved, CE Approved |
| Individualization | Write EPC, Laser code, Printing LOGO |
CL7203S-P9020
The RFID tags enable uniform companies, hospitality organizations, commercial cleaners, and medical facilities to automatically track clothing, linens, rags and other assets for accurate, efficient inventory management and accounting practices.
Parameters
| Functional specifications | |
|---|---|
| Protocol | EPC Class1 Gen2; ISO18000-6C |
| Frequency | 902-928MHZ ; 866-868MHZ |
| IC type | Alien higg3 |
| Memory | EPC 96bit User memory 512bit |
| Write cycles | 100,000 items |
| Size | 9020MM, Thickness 3MM, Hole 3MM2 |
| Operation Temperature | -20℃ to 100℃ |
| Storage Temperature | -40℃ to 140℃ |
| Weight | 12g |
| Material | FR4 |
| IP rating | IP68 |
| RF Specification | |
|---|---|
| Read range | 900CM-(902-928MHZ) (Fix reader) 900CM-(865-868MHZ) (Fix reader) 550CM-(902-928MHZ) (Handheld reader) 500CM-(865-868MHZ) (Handheld reader) |
| Test | 100% test with Voyantic |
